Khe cắm mở rộng | 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
1 x PCI Express x16 slot, running at x8 (PCIEX8)
2 x PCI Express x16 slots, running at x4 (PCIEX4_1, PCIEX4_2) |
Ổ cứng hỗ trợ | 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support) (M2P_32G)
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe x4/x2 SSD support) (M2M_32G)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2Q_32G)
6 x SATA 6Gb/s connectors (SATA3 0, 1, 4, 5, 6, 7)
Support for RAID 0, RAID 1, RAID 5, and RAID 10 |
Cổng kết nối (Internal) | 1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x water cooling CPU fan header
4 x system fan headers
2 x system fan/water cooling pump headers
1 x digital LED strip header
1 x digital LED strip power select jumper
2 x RGB (RGBW) LED strip headers
3 x M.2 Socket 3 connectors
8 x SATA 6Gb/s connectors
1 x Intel® VROC Upgrade Key header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB Type-C™ port, with USB 3.1 Gen 2 support
2 x USB 3.1 Gen 1 headers
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x power button
1 x reset button
1 x Clear CMOS button
1 x OC button
2 x temperature sensor headers |
Cổng kết nối (Back Panel) | 1 x PS/2 keyboard/mouse port
2 x USB 2.0/1.1 ports
2 x DisplayPort In ports
2 x Thunderbolt™ 3 connectors (USB Type-C™ ports, with USB 3.1 Gen 2 support)
4 x USB 3.1 Gen 1 ports
2 x RJ-45 ports
2 x MMCX antenna connectors (2T2R)
1 x optical S/PDIF Out connector
5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In) |
