THÔNG SỐ KỸ THUẬT
| Form factor | ATX |
| Chipset | Intel Z390 |
| Socket | 1151(v2) (8th and 9th Generation Intel CPUs) |
| RAM | 4x DDR4 (2666 MHz up to TBA MHz with overclocking) Dual-Channel Max. 64 GB |
| Slots (physical) | 1x PCIe 3.0 x16 2x PCIe 3.0 x16 (electrical x4) Multiple GPU configuration: 2-Way AMD CrossFire 4x PCIe 3.0 x1 |
| Internal Connections | 6× SATA 6G 1x M.2 (PCIe 3.0 x2 & SATA; 2242 / 2260 / 2280) 2x USB 3.0 Typ A (Header) 2x USB 2.0 (Header) 1x CPU-Fan-Header (4-Pin) 3x Fan-Header (4-Pin) 1x TPM-Header 1x Front Panel Audio C 1x COM-Header 1x RGB-LED-Header (4-Pin 12V) |
| External Connection | 2x PS/2 6x USB 3.0 1x HDMI 1x Gigabit-LAN (Realtek 8118) 6x Audio (Realtek 8118 Codec) |
| Power supply | 1x 24-Pin ATX 12V 1x 8-Pin ATX 12V 1x 4-Pin ATX 12V |
