PROCESSOR
Supports 9th / 8th Gen Intel® Core™ / Pentium® Gold / Celeron® processors for LGA 1151 socket
CHIPSET
Intel® Z390 Chipset
MEMORY
- 4 x DDR4 memory slots, support up to 64GB
- Supports DDR4 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(OC)/ 3000(OC) / 2800(OC)/ 2666/ 2400/ 2133 MHz
- Supports Dual-Channel mode
- Supports non-ECC, un-buffered memory
- Supports Intel® Extreme Memory Profile (XMP)
SLOTS
- 3 x PCIe 3.0 x16 slots (support x16/x0/x4, x8/x8/x4 modes)
- 3 x PCIe 3.0 x1 slots
ONBOARD GRAPHICS
- 1 x HDMI™ port 1.4, supports a maximum resolution of 4096x2160@24Hz
- 1 x DisplayPort port 1.2, supports a maximum resolution of 4096X2304@60Hz
MULTI-GPU
- Supports 2-Way NVIDIA® SLI™ Technology
- Supports 3-Way AMD® CrossFire™ Technology
STORAGE
Intel® Z390 Chipset
- 6 x SATA 6Gb/s ports1
- 2 x M.2 slot (Key M)1
- Support up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices
- Intel® Optane™ Memory Ready2
- M.2 slots and SATA ports share the bandwidth.
- Before using Intel® Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.
RAID
Intel® Z390 Chipset
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supports RAID 0, RAID 1 for M.2 PCIe storage devices
USB
Intel® Z390 Chipset
- 5x USB 3.1 Gen2 (SuperSpeed USB 10Gbps) ports (1 Type-C and 3 Type-A ports on the back panel, 1 Type-C internal connector)
- 4x USB 3.1 Gen1 (SuperSpeed USB) ports available through the internal USB connectors
- 6x USB 2.0 (High-speed USB) ports (2 Type-A ports on the back panel, 4 ports available through the internal USB connectors)
AUDIO
Realtek® ALC1220P-VB2 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
LAN
- 1 x Intel® I219-V Gigabit LAN controller
WIRSLESS LAN & BLUETOOTH®
Intel® Wireless-AC 9560
- Supports 802.11 a/b/g/n/ac, MU-MIMO Rx, 2.4GHz/ 5GHz (160MHz) up to 1.73Gbps
- Supports Bluetooth® 2.1, 2.1+EDR, 3.0, 4.0, 5
INTERNAL CONNECTORS
- 1 x 24-pin ATX main power connector
- 1x 8-pin ATX 12V power connector
- 1x 4-pin ATX 12V power connector
- 6x SATA 6Gb/s connectors
- 1x USB 3.1 Gen2 Type-C port
- 2x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1x 4-pin CPU fan connector
- 1x 4-pin Water Pump connector
- 5x 4-pin system fan connectors
- 1x Serial port connector
- 1x Front panel audio connector
- 2x System panel connectors
- 1x Thunderbolt Add-on Card Connector
- 1x Chassis Intrusion connector
- 1x TPM module connector
- 2x 4-pin RGB LED connectors
- 1x 3-pin RAINBOW LED connector
- 1x 3-pin CORSAIR LED connector
BACK PANEL PORTS
- PS/2 Combo Port
- LAN
- HD Audio Connectors
- USB 2.0
- DisplayPort
- HDMI
- USB 3.1 Gen2 Type-A + C
- USB 3.1 Gen2 Type-A
- Wireless / Bluetooth
- Optical S/PDIF out
